358 Fence

358 Fence

358 fence is made of a strong welded mesh plate with small meshes. It is extremely difficult to penetrate and attack with traditional hand tools. It has the functions of anti-climbing and anti-cutting.

Products description

1. Product description of 358 fence

358 fence made from a type of strong welded mesh panel with small mesh opening. It is extremely difficult to penetrate and difficult to attack using conventional hand tools, has the features of anti-climbing and anti-cutting. The fence name 358 fence comes from its panel mesh opening 3" × 0.5" × 8 gauge - approximate to 76.2 mm × 12.7 mm × 4 mm mesh opening. It is recommended to use a strong structure and corrosion resistance as a welded metal fence, galvanized after welding, and then PVC coating.

2. 358 fence application

358 fence is a high secure fence, suitable places include:

Prison.

Military sites.

Detention center.

Psychiatric hospital.

Airport.

Bridge.

Sub-station.

Shipping port.

Warehouse.

Power plant.

Laboratory.

Petroleum and chemical facilities guarding.

Industrial and commercial property, etc.

3. 358 fence specification

Mesh pattern: 76.2 mm (3") × 12.7 mm (0.5") resistance welded well at each intersec

Wire diameter: 4 mm horizontal wire and vertical Wire.

Weld strength: range 540-690 N/m2

Surface treatment: 358 mesh fence panels made from galfan wire, then PVC powder coating (min. 100 micron), or PVC powder painting. It provides additional protection and increases the potential life span.

Colours: Green RAL 6005, or Black RAL 9005.

Installation: Overlapped 75 mm minimum at each post for securing with slotted clamp bars and M8 diameter bolts.


Fence Height(M)

Panel Size(H*W)

Post(H*Size*Thick)

Clamp Bar(H*W*Thick)

Inter or comer clamp No(PCS)

2

2007mmx2515mm

2700x60x60x2.5mm

2007mmx60x5.00mm

7 or 14

2.4

2400mmx2515mm

3100x60x60x2.5mm

2400mmx60x5.00mm

9 or 18

3

2997mmx2515mm

3800x80x80x2.5mm

2997mmx80x6.00mm

11 or 22

3.3

3302mmx2515mm

4200x80x80x2.5mm

3302mmx80x6.00mm

12 or 24

3.6

3607mmx2515mm

4500x100x60x3.0mm

3607mmx100x7.0mm

13 or 26

3.6

3607mmx2515mm

4500x100x100x3.0mm

3607mmx100x7.00mm

13 or 26

4.2

4204mmx2515mm

5200x100x100x4.0mm

4204mmx100x8.0mm

15 or 30

4.5

4496mmx2515mm

5500x100x100x5.0mm

4496mmx100x8.00mm

16 or 32

5.2

5207mmx2515mm

6200x120x120x5.0mm

5207mmx100x8.00mm

18 or 36


4. Application scenario


358 Fence


358 Fence


358 Fence


Anping Xinghong Metal Wire Mesh Co., Ltd. is a leading 358 fence manufacturer and supplier in China. We provide high-quality and low-cost 358 fence , or contact us to send your customized requirements, we will design and extend suitable for you wire mesh.
